SMC Networks HRSH200-A*-20 Series User Manual

HRX-OM-Q026-B
Chapter 8 Documents
8.5 Pump capacity HRSH Series
8-8
8.4.3 HRSH250-A∗-20／40-∗
0
5
10
15
20
25
30
5 101520253035
Circulating fluid temperature [℃]
Cooling capacity [kW]
Fig. 8-6 Cooling capacity(HRSH250-A∗-20／40-∗)
8.5 Pump capacity
8.5.1 HRSH150／200-A∗-20-∗
Fig. 8-7 Pump capacity (HRSH150／200-A∗-20-∗)
0
0.1
0.2
0.3
0.4
0.5
0.6
0 102030405060708090100110120130
Circulating fluid flow [L/min]
Pressure [MPa]
0
10
20
30
40
50
60
Lifting head [m]
Usable flow rate ran
g
e
Ambient temperature: 32
o
C
Ambient temperature: 43
o
C
Ambient temperature: 45
o
C
Circulating fluid
return
p
ort
Circulating fluid
outlet port
