HRX-OM-Q026-B
Chapter 4 Starting the Product
HRSH Series 4.2 Preparation for Start
4-3
Press
ON
4.2.3 For HRSH∗∗∗-A∗-40-∗
Turn on the breaker handle. The status will become the clause 4.2.1 Power supply.
Fig. 4-2 Position of the breaker handle
4.2.4 Setting of circulating fluid temperature
Press the [▼] and [▲] buttons on the operational panel to change the SV to
required value.
When the temperature of the circulating fluid is set by the communication,
refer to "Communication” in the supplementary operation manual.
Fig. 4-3 Setting of circulating fluid temperature
4.2.5 Setting of pump operation mode
The initial setting of the pump operation mode is pressure controlled mode
and the pressure setting is 0.5MPa. Regarding the pump operation mode,
refer to “5.16Pump operation mode function”.
