SMC Networks HRSH200-A*-20 Series - Wiring of Operation Signal Output and Alarm Signal Output

HRX-OM-Q026-B
Chapter 3 Transport and Setting Up
HRSH Series 3.3 Installation
3-21
3.3.7 Wiring of operation signal output and alarm signal output
The operation signal output and alarm signal output are the outputs
generated by a contact signal to shown the status of the product.
The specifications of the contact for each signal output are as follows.
Table 3-9 Signal output contact spec. at the time of shipment
Contact output
Signal explanation
(Default setting)
Operation
At run：
Contact closed
At stop：
Contact open
Contact output signal 1
（Terminal no.0,8）
Operation status signal
output
A
With power supply
shut off：
Contact open
At remote：
Contact closed
At non remote：
Contact open
Contact output signal 2
（Terminal no.1,9）
Remote status signal
output
A
With power supply
shut off：
Contact open
At generation：
Contact open
Not generated：
Contact closed
Contact output signal 3
（Terminal no.2,10）
Alarm status signal
output
B
With power supply
shut off：
Contact open
【Tips】
This product has three output signals which can be customized depending on
the customer’s application
Signals below can be output. Refer to the Communications Operation Manual
for more details.
・Ready completion (TEMP READY) signal output
・Operation stop alarm signal output
・Operation continuation alarm signal output
・Selected alarm status signal output
・Operation start timer setting status signal output
・Operation stop timer setting status signal output
・Recovery from power failure setting status signal output
・Anti-freezing setting status signal output
・Contact input signal1, 2 pass through signal output
・Warming up function setting status output
・Anti-snow coverage function setting status output
Be sure to lock out and tag out the breaker of the facility power supply
(customer power supply facility) before wiring.
