SMC Networks HRSH200-A*-20 Series User Manual

HRX-OM-Q026-B
Chapter 4 Starting the Product
HRSH Series 4.3 Preparation of circulating fluid
4-5
2. Press the [RESET] key ([▼] and [▲] keys simultaneously) to stop the alarm buzzer.
Fig. 4-6 Alarm receipt
3. Automatic fluid-fill was already started. After the fluid is supplied more than “LOW” level,
the alarm can be reset. Refer to clause 4.
 For the option K [Fluid fill port]
Fill the circulating fluid to the fluid fill port up to the level between “HIGH” and “LOW” of the fluid
level gauge.
Be sure to reset the alarm on the operation display panel of the alarm. Alarm reset
is not accepted from any screen except the alarm display menu. Refer to 5.1.1 Key
operations.
Flash
Press together
ON
