SMC Networks PF2M7 Series User Manual

-26-
No.PF※※-OMW0007-A
■Default setting
The default setting is as follows.
If no problem is caused by this setting, keep these settings.
To change a setting, enter function selection mode.
Item
Default setting
Page
[F 0]  [FLU]
[FLU] Switch the flow rate
[Air] Dry air, N
2
Page 27
[rEF] Setting the units criteria
[Std] Standard condition
[Unit] Measurement unit switching
1
[ L] L/min (L)
[F 1]  [oUt1]
[oUt1] Setting of OUT1
[HYS] Hysteresis mode
Page 29
[1ot] OUT1 output configuration setting
[1_P] Normal output
[P_1] Set value
[ ] 50% of maximums rated flow
PF2M710: 5 L/min, PF2M725: 12.5 L/min
PF2M750: 25 L/min, PF2M711: 50 L/min
[H_1] Hysteresis
[ ] 5% of maximums rated flow
PF2M710: 0.5 L/min, PF2M725: 1.3 L/min
PF2M750: 2.5 L/min, PF2M711: 5 L/min
[dt1] Delay time setting
[0.00] 0.00 s
[CoL] Display colour setting
[1SoG] ON: Green OFF: Red
[F 2]  [oUt2]
[oUt2] Setting of OUT2
2
[HYS] Hysteresis mode
Page 34
[2ot] OUT2 output configuration setting
2
[2_P] Normal output
[P_2] Set value
2
[ ] 50% of maximums rated flow
PF2M710: 5 L/min, PF2M725: 12.5 L/min
PF2M750: 25 L/min, PF2M711: 50 L/min
[H_2] Hysteresis
2
[ ] 5% of maximums rated flow
PF2M710: 0.5 L/min, PF2M725: 1.3 L/min
PF2M750: 2.5 L/min, PF2M711: 5 L/min
[dt2] Delay time setting
2
[0.00] 0.00 s
[CoL] Display colour setting
2
[1SoG] ON: Green OFF: Red
[F 3]  [FiL]
[FiL] Digital filter setting
[1.0] 1.0 s
Page 38
[F 4]  [PrS]
[PrS] Auto-preset function setting
[oFF] Manual
Page 39
[F10]  [FLo]
[FLo] Display mode
[inS] Instantaneous flow
Page 41
[F11]  [drE]
[drE] Display resolution setting
[1000] 1000-split
Page 42
[F13]  [rEv]
[rEv] Set Reverse display
[oFF] Not reverse
Page 43
[F14]  [CUt]
[CUt] Zero cut-off setting
[1.0] 1% of maximums rated flow
PF2M710: 0.1 L/min, PF2M725: 0.3 L/min
PF2M750: 0.5 L/min, PF2M711: 1 L/min
Page 44
[F22]  [AoUt]
[AoUt] Analogue output setting
3
[1-5] 1 to 5 V Voltage output (when voltage is output)
[---] Analogue output is not selectable (for current type output)
Page 45
[F30]  [SAvE]
[SAvE] Accumulated flow value hold setting
[oFF] Not held
Page 47
[F80]  [diSP]
[diSP] Display OFF mode setting
[ on] Normal display
Page 48
[F81]  [Pin]
[Pin] Security code
[oFF] Unused
Page 49
[F90]  [ALL]
[ALL] Setting of all functions
[oFF] Unused
Page 50
[F98]  [tESt]
[tESt] Output checking
[ n] Normal output
Page 52
[F99]  [ini]
[ini] Reset to the default settings
[oFF] Not recover
Page 54
1: Setting is only possible for models with the units selection function.
2: Only available for models with switch outputs for both OUT1 and OUT2.
3: This function is available for models with analogue output.
Analogue free span function can be selected.
