SMC Networks PF2M7 Series User Manual

-69-
No.PF※※-OMW0007-A
■Characteristics data
●Flow rate/Analogue output
A
B
2
C
PF2M710/750/711
PF2M725
Voltage output (1 to 5 V)
1 V
1.04 V
1.05 V
5 V
Current output (4 to 20 mA)
4 mA
4.16 mA
4.19 mA
20 mA
E
F
G
PF2M710/750/711
PF2M725
Voltage output (0 to 10 V)
1
0 V
0.10 V
0.12 V
10 V
1: The analogue output current from the connected equipment should be 20 μA or less when selecting 0 to 10 V.
When more than 20 μA current flows, it is possible that the accuracy will not be satisfied below 0.5 V.
2: D or H changes based on the setting of the zero cut-off function.
When the zero cut-off function is set to “0”, the display starts from 0 L/min. In conditions other than horizontal installation and
0.35 MPa supply pressure, the output may not be 0 L/min.
