-52-
No.PF※※-OMW0007-A
■[F98] Setting of output check
The switch output and analogue output can be checked.
The output can be turned ON/OFF manually.
<Operation>
Press the UP or DOWN button in function selection mode to display [F98].
Press the SET button. Move on to the setting of output check.
Move on to output check of OUT1.
Check of OUT1 output
Press the UP or DOWN button to
select the OUT1 output check.
Press the SET button to set. Move on the OUT2 output check.
[F] (Fixed output) is selected
Press the SET button to set.
Setting of output check
Press the UP or DOWN button to select
output check.
[n] (Normal
output)is
selected
Press the
SET button to
return to
function
selection
mode.
