Hysteresis mode: [H_1]
Window comparator mode: [ H1]
The snap shot function can be used.
(Refer to page 55)
Delay time set range: 0.00 to 60.00 [s]
Hysteresis setting
Set the pressure referring to the setting
method on page 24.
Move on to delay time
setting.
Press the SET button
to set.
Delay time setting
Press the UP or DOWN button to select
the delay time.
Move on to display
colour setting.
Press the SET button
to set.
