SMC Networks PF2M7 Series User Manual

-67-
No.PF※※-OMW0007-A
Model
PFM710
PFM725
PFM750
PFM711
Analogue output
9
Output type
Voltage output: 1 to 5 V (or 0 to 10 V)
10
, Current 4 to 20 mA
Impedance
Voltage
Output impedance approx.1 kΩ
Current
Max. load impedance Power supply voltage 24 V: 600 Ω
Power supply voltage 12 V: 300 Ω
Response time
6
50 ms ±40%
Display
Reference condition
11
Select from normal condition (STD) and Standard condition (NOR)
Output mode
Select from instantaneous flow and accumulated flow
Unit
12
Instantaneous flow
L/min, cfm
Accumulated flow
L, ft
3
Displayable
range
Instantaneous flow
-0.5 to 10.5 L/min
-1.3 to 26.3 L/min
-2.5 to 52.5 L/min
-5 to 105 L/min
Zero cut-off range
0 to ±10%F.S. (selected for every 1%F.S. of max. rated flow rate)
Accumulated flow
13
0.0 to 99999999.9 L
0 to 999999999 L
Display
Display type: LCD, Display colour: Red, green, Display digit: 7-segment, 4 digits
Operation LED
LED is ON when switch output is ON, OUT1/OUT2: Orange
Digital filter
14
Select from 0.05 s, 0.1 s, 0.5 s, 1 s, 2 s and 5 s
Environmental
resistance
Enclosure
IP40
Withstand voltage
1000 VAC, 1 min. between terminals and housing
Insulation resistance
50 MΩ or longer (with 500 VDC) between terminals and housing
Operating temperature
range
Operation: 0 to 50
o
C, Storage: -10 to 60
o
C (no freezing or condensation)
Operating humidity range
Operation, Storage: 35 to 85%R.H. (no freezing or condensation)
Standards
CE marked (EMC directive, RoHS directive)
Piping
15
Piping specification
C6 (6)
C8 (8)
Port direction
Straight
Material fluid contact parts
PPS, PBT, FKM, SUS304, brass (Electroless nickel plating), Si, Au, GE4F
Weight
Body
40 g
48 g
Flow adjustment valve
+34 g
Lead wire
+35 g
Bracket
+20 g
Panel mount adapter
+15 g
DIN rail mounting bracket
+65 g
