SMC Networks PF2M7 Series

-77-
No.PF※※-OMW0007-A
Panel cut-out dimensions
Flow adjustment valve
A
None
54
＋0.5
0
With flow adjustment valve
74
＋0.5
0
1: If a bend (R) is used, limit it to R3 or less.
2: Suitable for panel thickness of 1 to 3.2 mm.
Bracket (ZS-33-M)
Bracket (ZS-33-MS)
