The Segmentation Concept
Each TigerStack hub is composed of two or four repeater
groups, with each group containing four or seven ports, de-
pending upon the model. Thus, a stack eight high can have as
many as 32 repeater groups. Initially, these groups are united
into a single 10 Mbps segment via the inter-repeater bus which
runs through the stacking cable.
SEGMENTING
30
3306FC Segments A and B
3306BC Segments A and B
3328TELCO Segments A, B, C, and D
3328T Segments A, B, C, and D
(the 3314T has Two Segments: A and B)
3326TA Segments A, B, C, and D
(the 3312TA has Two Segments: A and B)
