AUI Pin Assignments
Note: Voltage Plus (VP) and Voltage Common (Vc) use a
single twisted-pair in the AUI cable.
63
CABLES
Pin Circuit Signal Name
3 DO-A Data Out Circuit A
10 DO-B Data Out Circuit B
11 DO-S Data Out Circuit Shield
5 DI-A Data In Circuit A
12 DI-B Data In Circuit B
4 DI-S Data In Circuit Shield
8 CO-S Control Out Circuit Shield
2 CI-A Control In Circuit A
9 CI-B Control In Circuit B
1 CI-S Control In Circuit Shield
6 Vc Voltage Common
13 VP Voltage Plus
14 VS Voltage Shield
Shell PG Protective Ground
(Conductive Shell)
AUI Pin Assignments
