SMC Networks TigerStack - Crossover RJ-45 Pin Assignments; Crossover Wiring

Crossover Wiring
If the twisted-pair link segment is to join two ports and either
both ports are labeled with an “X” or neither port is labeled
with an “X,” a crossover must be implemented in the wiring.
Pin assignments for Telco connectors are given on the next
page.
CABLES
60
End 1 End 2
1 (Tx+) 3 (Rx+)
2 (Tx-) 6 (Rx-)
3 (Rx+) 1 (Tx+)
6 (Rx-) 2 (Tx-)
Crossover RJ-45 Pin Assignments
