Cable Specifications
51
CABLES
Type 100 ohm UTP
(e.g., IBM Type 3 or AT&T DIW)
Number of Pairs 2
Max. Link Segment Length 328 ft. (100 m)
Min. Link Segment Length 2.0 ft. (0.6 m)
Max. Number of Attachments 2
per Link Segment
Type 78 ohm STP
Max. Drop Cable Length 165 ft. (50 m)
Min. Drop Cable Length 0.0 ft. (0.0 m)
Max. Number of Attachments 2
per Drop Cable
Type 50 ohm Coax
Max. Segment Length 1,640 ft. (500 m)
Min. Distance Between 8.2 ft. (2.5 m)
Transceivers
Max. Number of Attachments 100
per Cable Segment
Twisted-Pair Link Segment Specifications
Thick Coax Cable Specifications
AUI Cable Specifications
