SMC Networks TigerStack - 3306 FC Segment Buttons a and B; Linking 10 BASE-T Segments through a Switch

Interconnecting Isolated Segments
Suppose you have a number of small, high-traffic workgroups
that do need to share data and also need additional bandwidth.
Once isolated from the bus, these workgroups can be intercon-
nected through a switch.
Linking 10BASE-T Segments Through a Switch
33
SEGMENTING
3306FC Segment Buttons A and B
Switch
Servers
Workstations
TigerStack
Multiple
10 Mbps
Uplinks
