Extended Distance
The IEEE 802.3 10BASE2 specification defines the maximum
length of a thin coax segment as 607 feet (185 m). However,
TigerStack BNC ports support thin coax segments of up to
1,000 feet (305 m) in length with 50 ohm RG-58 cabling meet-
ing the following specifications:
Note: If other Ethernet products are attached to the same
cable segment, then the maximum length of that cable
segment is limited by the length these products support.
53
CABLES
Number of Nodes Nominal Attenuation at 10 MHz
per 1,000 feet (305 m) per 100 feet (30 m)
Maximum 10 13 dB or less 1.3 dB or less
Maximum 30 12 dB or less 1.2 dB or less
Extended Distance Specifications
