Servodrives / inverters series COSMOS 301X Installation, use and maintenance manual - EN
4.2.4 Dynamic brake output
Type Control circuit of the brake resistor with IGBT
Protections Against brake resistor short-circuit
Brake resistor resistance 30 ÷ 150 Ω
Average available power 150 W max.
4.2.5 Encoder input
Type Input for readout of incremental encoder with 5 V differential signals
Maximum input frequency 200 kHz
Power supply 5 V, max 200 mA
4.2.6 Resolver input
Type Input for resolver readout
Excitation signal frequency 5 kHz
4.2.7 Digital inputs
Type (KZ010375 and KZ010376)
24 V digital inputs, compatible with type 1 and type 3, according to
IEC 61131-2
Type (other versions) 24 V digital inputs
Max. frequency of input signal 1 kHz
4.2.8 Digital outputs
Type 24 V pnp (current-sourcing) digital outputs
Maximum available current 30 mA
Protections Against short-circuit, overload and overheating
4.2.9 Static brake output
Type (KZ010377 and KZ010389) 24 V pnp (current-sourcing) digital output
Type (KZ010387 and KZ010388) 24 V npn (current-sinking) digital output
Max. available current 500 mA
4.2.10 Counter input
Type 24 V digital input
Maximum input current 4.5 mA @ V
in
=24 V
Input signal frequency range 0 ÷ 100 kHz
4.2.11 0 ÷ 10 V input
Input voltage range 0 ÷ 10 V DC
Input resistance 147 kΩ typ.
Resolution 12 bit
Ver. 1.09 SMITECdd 14/74
