4.4 Model code
The specific features of a servo-driver/inverter of the COSMOS 301X series are defined by an alpha-numeric
code printed on the device label, near the MODEL code. Here is the code table:
Ver. 1.09 SMITECdd 18/74
MODEL * * * * * . * * * * * . * * * * *
Reserved
Reserved
Auxiliary power
1 = 24Vdc
Main power
1 = 230Vac 1PH
Maximum output current - Asynchronous motor power
1 = 15Apk – 0,75kW
2 = 2 x 12Apk – 0,370kW
Dynamic brake
0 = Absent
1 = Present
Encoder inputs and thermocouple
0 = Absent
1 = Incremental 5V diff. AB
2 = Incremental 5V diff. AB+UVW
3 = Resolver
4 = Resolver + Incremental 5V diff. AB
5 = Resolver + Incremental 5V diff. AB+UVW
6 = TC + Incremental 5V diff. AB
7 = T C + Incremental 5V diff. AB+UVW
8 = TC
Motor brake
0 = Absent
1 = Present
Physical layer communication/fieldbus
0 = Absent
1 = EIA-RS485, 2 ports, max 2.5Mbps, automatic termination
2 = EIA-RS485, 1 porta, max 2.5Mbps, no termination
3 = EIA-RS485, 1 porta, max 250kbps, no termination
4 = EIA-RS485, 1 porta, max 2.5Mbps, termination inserted
Support VISION 3000
0 = Absent
1 = Present
Pulse counter digital input
0 = Absent
1 = Present
Common digital inputs
0÷9 = 0÷9 inputs i
A÷G = 10÷16 inputs
Common digital outputs
0÷6 = 0÷6 outputs
Analog input
0 = Absent
1 = 0÷10V
2 = 4÷20mA
3 = 0÷10V/POT
4 = 0÷10V/POT + 4÷20mA
Analog output
0 = Absent
1 = 0÷10V
