Servodrives / inverters series COSMOS 301X Installation, use and maintenance manual - EN
5.10.1 Function of the keys
◄
Navigation: By pressing the left arrow key, you return to a higher level menu. If you are in the main
menu, the screen showing the device status is displayed. From this screen, you can press the left key
again, for displaying the firmware version and the servo-drive model.
Modify data: this key moves the cursor to the digit immediately on the left of the one currently indicated
by the cursor. If the cursor is positioned over the digit on the extreme left, the cursor will not move. It is
possible to cancel a change in progress (that is a change that has not been confirmed yet), by holding
down this key for 1 second.
►
Navigation: By pressing the right arrow key, you can move to the lower level menu. The active entry is
situated on the first line on the LCD and is indicated by the flashing character “ > “ on the left of the
wording.
Modify data: By holding down this key for at least 1 second, the system will enter the modification mode
for the selected parameter, if it can be modified under the current conditions and if you are at a level of
access that allows the parameter to be modified. When the cursor is under the character on the farthest
right in the field, this means that the system is in the modification mode: if you press the key, the cursor
will move to the digit immediately to the right of the currently indicated digit. If the cursor is positioned
over the digit on the extreme right, it will not move. To confirm a modification, hold down this key for at
least 1 second.
▲
Navigation: the up arrow key moves the system to the previous item in the current menu. The key will
have no effect, if you are already positioned on the first item.
Modify data: this key increases the digit where the cursor is positioned. If the digit reaches the maximum
value allowed, the LCD will try to increase the digit on the immediate left (unless it is at its maximum
level, too).
▼
Navigation: the down arrow moves the system to the next item in the menu. The end of the list of items
in the menu is indicated by a line consisting of minus signs (----).
Modify data: this key decreases the digit where the cursor is positioned. If the digit reaches the minimum
value allowed, the LCD will try to decrease the digit on the immediate left, unless it is at its minimum
value, too.
Ver. 1.09 SMITECdd 64/74
