Servodrives / inverters series COSMOS 301X Installation, use and maintenance manual - EN
Protection for UL applications according to IEC / UL 61800-5-1 and C22.2 No.274
The characteristics of the recommended fuses are summarized in the following tables:
COSMOS 301X
Marking Mersen
Model FR10GR69V16
Class gR (IEC 60269-4)
Dimension 10x38 mm
Rated current 16 A
Working voltage 700V AC
Suitable For Use On A Circuit Capable Of Delivering Not More Than 5000 Arms
Symmetrical Amperes, 230 Vac Maximum when protected by semiconductor fuses model
FR10GR69V16 by Mersen.
5.5 Installation criteria for UL certification
Integral solid state short circuit protection does not provide branch circuit protection.
Branch circuit protection must be provided in accordance with the Manufacturer
Instructions, National Electrical Code and any additional local codes.
The drive does not provide Motor Overload protection. External or remote Motor Overload
protection shall be provided in the end-use applications.
The drive is intended to be used with motors that must have integral thermal protection.
The integral thermal protection signal shall be connected on the equipment, on terminal
"J4", pins 1-2 for models 301X-XX and also terminal "J3", pins 7-8 only for model 3010-
RU.
Signal was rated maximum 5Vdc, 5mA.
Ver. 1.09 SMITECdd 36/74
