Smitec 3010FA - Connections (KZ010385)

Servodrives / inverters series COSMOS 301X Installation, use and maintenance manual - EN
5.3.4 Connections (KZ010385)
The following picture shows the arrangement of the connectors and terminal boards:
Ver. 1.09 SMITECdd 30/74
TOP VIEW BOTTOM VIEWFRONT VIEW
230VAC POWER SUPPLY,
PE AND MAINS FILTER
FIELD BUS
MOTOR OUTPUTS, DC BUS
AND BRAKE RESISTOR
24VDC POWER SUPPLY
AND I/O
24VDC POWER SUPPLY
AND I/O
ENCODER
HMI
