10
Introduction Scope Multimeter Module
2.3.2 Technical Specifications
Dimensions:
Length:
6.75 inches
171.5 mm
Height:
5.1 inches
129.5 mm
Depth:
0.89 inches
22.6 mm
Weight (including protective hand grip):
0.66 lbs.
0.30 kg
Operating Temperature Range (ambient):
At 0 to 90% relative humidity (non-condensing)
32 to 113°F
0 to 45°C
Storage Temperature (ambient):
At 0 to 70% relative humidity (non-condensing)
–4 to 140°F
–20 to 60°C
Environmental Conditions:
This product is intended for indoor use only
This product is rated for Pollution Degree 2 (normal conditions)
2.3.3 Power Sources
The Scope Multimeter Module operates on USB power (5V @ 500mA) supplied by the Display
Device. Power is provided either through direct connection to the Display Device, or through a
USB cable when the Scope Multimeter Module is separated from the Display Device.
