-49-
Appendix: The EMB Cartridge
The EMB cartridge.
The Scanner can work either with:
-the Primary Cartridge (for communication with the car) plus an (optional)
expert system (Trouble Shooter) cartridge, or
-the Extended Memory Board (EMB) Cartridge plus the Vehicle
Communication Interface (VCI) Cartridge.
The advantages of the EMB Cartridge over the Primary Cartridge are:
- The EMB can contain software for either one car brand (previously referred
to as Primary Cartridge) or a range of car brands for easier and faster
working procedures.
-It can also contain the expert system software on the same EMB cartridge.
-The EMB is re-programmable giving a flexible approach to updates.
In order to operate the Scanner with the EMB, both slots in the Scanner are
used:
• One slot for the Vehicle Communication Interface (VCI)
Contains the communication interface between the EMB Cartridge and the
Vehicle.
• One slot for the EMB Cartridge
Contains the program(s) per car brand.
The Cartridges can be identified by the decal.
Installation Instructions.
1. Insert the VCI Cartridge in the left hand slot at the bottom of the Scanner.
2. Insert the EMB Cartridge in the right hand slot.
Note: The EMB Cartridge will not work if the VCI is replaced by a
Primary Cartridge or Trouble Shooter Cartridge.
Note: If you wish to use a Primary Cartridge or Trouble Shooter
Cartridge, refer to the setup as described in Scanner Manual,
Section Operation.
Operation.
Apart from the installation and the introduction of the selection of the car brand
in the first menu, there is no difference in operation when compared to the Primary
Cartridge.
