Wire EDM Machine Operation Chapter 13
Copyright November, 98 Page 13-2 Sodick Inc.
Note: (A320D & A530D only) If the plotting table is up and the side door is shut, DO
NOT put the plotting pen arm on or it will hit the cover!!!!!!
10) Move machine back to the start point location and check machine numbers.
a) Use the horizontal soft-key “G30 START” to move back to the position set
with the “G92” code.
11) Steps to actually start up the program. If everything looks correct, then cut the part.
a) Be sure you are already in the “RUN” screen from step 10 above.
b) Press “Arrow Up” then “Home Clear” keys to start at the top of the file.
c) Change the “DRY” horizontal soft-key to “0”. Do not use the “Enter” key
while changing this parameter.
d) Press the “Enter” key to cut the program.
e) When machining begins, the cutting conditions can be modified to speed up or
slow down the machine. See page 1-12 for tips on modifying the conditions on
the rough cut.
