Wire EDM Machine Operation Chapter 6
Copyright November, 98 Page 6-4 Sodick Inc.
L
L
I
I
S
S
T
T
O
O
F
F
G
G
C
C
O
O
D
D
E
E
S
S
Code Description Modal
G00 Rapid Motion (appears as a dotted line in graphics) pg. 5-1 Y
G01 Straight Line Cutting Motion pg. 5-2 Y
G02 Circular Cutting Motion - Clockwise (CW) pg. 5-3 Y
G03 Circular Cutting Motion - Counterclockwise (CCW) Y
G04 Dwell (ex: G04 x5.0 to dwell for 5 seconds at sharp corner only) N
G05 X Axis Mirror image (turns CRT readout red when on) pg.10-10 Y
G06 Y Axis Mirror Image (turns CRT readout red when on) pg. 10-10 Y
G08 X-Y Exchange (turns x,y,u,v, to lower case letters when on) Y
G09 Cancel G05, G06, G08 Y
G11 Block Skip On (activates slash code, /, in NC program) pg. 6-1 Y
G12 Block Skip Off pg. 6-1 Y
G13 AWT REF=1 Wire break recovery with C888 discharge Y
G14 AWT REF=0 Wire break recovery turned off Y
G15 AWT REF=2 Wire break recovery without C888 discharge Y
G20 Inch Mode Y
G21 Metric Mode Y
G22 Soft Limit On pg. 15-21 Y
G23 Soft Limit Off pg. 15-21 Y
G26 Pattern Rotation On (ex: G26 RA45.0) pg.10-16 Y
G27 Pattern Rotation Off Y
G28 Return To G29 Reference Point N
G29 Reference Point Memory (for auto wire threader) pg. 6-7 N
G30 Return To The Last G92 Location N
G40 Wire Radius Compensation Cancel pg. 7-1 Y
G41 Wire Radius Compensation Left pg. 7-1 Y
G42 Wire Radius Compensation Right pg. 7-1 Y
G50 Taper Cancel pg. 8-1 Y
G51 Taper Left pg. 8-1 Y
G52 Taper Right pg. 8-1 Y
G54 Work Coordinate System Number 0 pg.3-4 Y
G55 Work Coordinate System Number 1 pg.3-4 Y
G56 Work Coordinate System Number 2 pg.3-4 Y
G57 Work Coordinate System Number 3 pg.3-4 Y
G58 Work Coordinate System Number 4 pg.3-4 Y
G59 Work Coordinate System Number 5 pg.3-4 Y
G74 4 Axis On Y
G75 4 Axis Off Y
G80 Sensor touch pg.14-5 Y
G81 Move To Limits pg.14-1 N
