SODICK A320D - Changing the Axis Display Read any Number

Wire EDM Machine Operation Chapter 14
Copyright November, 98 Page 14-6 Sodick Inc.
C
C
H
H
A
A
N
N
G
G
I
I
N
N
G
G
T
T
H
H
E
E
A
A
X
X
I
I
S
S
D
D
I
I
S
S
P
P
L
L
A
A
Y
Y
R
R
E
E
A
A
D
D
A
A
N
N
Y
Y
N
N
U
U
M
M
B
B
E
E
R
R
This procedure will allow you to change the axis display to a value. This is commonly
used when setting the origin.
1) Go to the “MAL”,”MDI” screen.
To set axis display toZero:
2) Type G92XYUVZ and press “ENTER” .
To set to any number:
3) Type G92 and the values you want for X, Y, U, V, and press “ENTER” .
“G92X.500 Z0”
Note that all axis (X,Y, U,V,Z.) need not be included. If you are only interested in setting
one axis
(X for example), you would type “G92X” and press enter.
