Wire EDM Machine Operation Chapter 6
Copyright November, 98 Page 6-5 Sodick Inc.
Code Description Modal
G82 Move To Half Of Axis Display pg. 10-7 N
G83 Read Current Position and Store To An H Register pg. 10-7 N
G90 Set Absolute Mode Y
G91 Set Incremental Mode Y
G92 Assign Values to Axis Displays In Current Work Coordinate p3-3 N
G97 Assign Values to Axis Displays In ALL Work Coordinates N
G104 Dwell At All Sharp Corners (ex: G104 X5.0) Y
G105 Cancel G104 code Y
G140 4Axis Offset Off N
G141 4Axis Offset Left Y
G142 4Axis Offset Right Y
G154 TO G159 Work Coordinate Screen 10 to 15 pg. 3-4 Y
G254 TO G259 Work Coordinate Screen 20 to 25 pg. 3-4 Y
G354 TO G359 Work Coordinate Screen 30 to 35 pg. 3-4 Y
G454 TO G459 Work Coordinate Screen 40 to 45 pg. 3-4 Y
G554 TO G559 Work Coordinate Screen 50 to 55 pg. 3-4 Y
G654 TO G659 Work Coordinate Screen 60 to 65 pg. 3-4 Y
G754 TO G759 Work Coordinate Screen 70 to 75 pg. 3-4 Y
G854 TO G859 Work Coordinate Screen 80 to 85 pg. 3-4 Y
G954 TO G959 Work Coordinate Screen 90 to 95 pg. 3-4 Y
FLAG2D0 M01 code off pg. 15-14 Y
FLAG2D1 M01 code on pg. 15-14 Y
FLAG3D**** scale factor input pg. 10-13 Y
L
L
I
I
S
S
T
T
O
O
F
F
T
T
C
C
O
O
D
D
E
E
S
S
Code Description
T80 Wire Drive On
T81 Wire Drive Off
T82 Worktank Drain Closed
T83 Worktank Drain Open
T84 High Pressure Flushing Mode On (high flush)
T85 High Pressure Flushing Mode Off (low flush)
T86 Flushing Pump On
T87 Flushing Pump Off
T89 Switch To Non-Submersed Machining
T90 Cut Wire By Auto Wire Threader Sequence One
T91 Thread Wire By Auto Wire Threader Sequence Two
T94 Switch To Submersed Machining
T96 Worktank Fill Pump On
T97 Worktank Fill Pump Off
Note: Out of the above T codes, the only codes that are usually used in an NC program
