Wire EDM Machine Operation Chapter 14
Copyright November, 98 Page 14-22 Sodick Inc.
C
C
H
H
A
A
N
N
G
G
I
I
N
N
G
G
P
P
O
O
W
W
E
E
R
R
S
S
E
E
T
T
T
T
I
I
N
N
G
G
S
S
W
W
H
H
I
I
L
L
E
E
M
M
A
A
C
C
H
H
I
I
N
N
I
I
N
N
G
G
In the RUN mode, you have complete control of all condition parameters (ON, OFF,
IP,,HP,MA etc.) while running a part. However, when you start changing these
parameters, remember that you will be also changing important attributes of what the
condition will do (accuracy, finish, size, etc.).
1) “RUN” a program.
2) Press the soft key under the condition parameter you wish to change (parameter
will highlight in blue).
3) Type the new parameter value.
4) Press the soft key under the condition parameter (again) to enter it.
Note: If condition change in the “SET” screen is 0 any changes made are not saved (the
next time this C condition is called, the original setting returns). If condition set is on 1,
then the condition file changes.
When condition change is on 1, the change is only made to the RAM. When the machine
is rebooted, the condition file on disk is loaded to memory (original file). So if you want
the change to be permanent, then save the condition file using the “EDIT”,“FILE” screen.
S
S
W
W
I
I
T
T
C
C
H
H
I
I
N
N
G
G
B
B
E
E
T
T
W
W
E
E
E
E
N
N
M
M
A
A
C
C
H
H
I
I
N
N
E
E
C
C
O
O
N
N
T
T
R
R
O
O
L
L
A
A
N
N
D
D
“
“
A
A
P
P
T
T
”
”
Switching from machine control to APT programming.
1) From the CNC side Main Menu, press the soft key next to UTY.
2) Press the soft key next to APT.
3) At the prompt, insert the APT disk in drive one (remove the system disk first).
Delete this step if you have a hard drive.
4) Press the ENT key.
5) Press the F1 key.
6) At the USER DISK prompt, press the RETURN key.
7) The control will show a list of programs. If this is correct USER DISK, press Y
to say yes.
Switching from APT to the machine control:
1) From the initial page of the conversational side (with basic menu), type 10 for
“End of APT Function”.
2) Replace the SYSTEM DISK in drive one when prompted to and then press return.
press “ESC” if you have a hard drive.
3) Press the F10 key when prompted to return to the CNC side.
