Wire EDM Machine Operation Chapter 14
Copyright November, 98 Page 14-20 Sodick Inc.
5) Place the master SYSTEM disk in drive 1.
6) Press “ENTER” .
Note: This procedure takes about 15 minutes.
Controls with a hard drive cannot perform this procedure.
I
I
N
N
I
I
T
T
I
I
A
A
L
L
I
I
Z
Z
I
I
N
N
G
G
A
A
N
N
E
E
W
W
U
U
S
S
E
E
R
R
D
D
I
I
S
S
K
K
E
E
T
T
T
T
E
E
The USER disk is where you can store programs. As time goes on, you will fill the USER
disk with programs and need to use a new one. You should know that when initializing a
new USER disk, the current version of the condition file is placed on the new USER disk.
NOTE: Pre-formatted IBM double sided, double density disks (720KB)
do not need to be initialized with the procedure below.
Any useful programs like 0145 and 0165 etc. must also be saved onto the new user disk.
Note that any good quality, 3 1/2 inch double sided, double density disk (2DD) will work
for the user disk. This type of disk will have the square window in the lower left corner
only.
1) Press the soft key next to “SET”.
2) Press the soft key next to “DISK”.
3) Place the BLANK disk in drive 2 if you do not have a hard drive OR
Place the BLANK disk in drive 1 if you do have a hard drive.
4) Press the soft key under “USER FORMAT” and press the Y key.
5) Select dipro format (720 KB). Please note that the 1 MB standard format is NOT
IBM compatible.
6) Press “ENTER” (initializing takes about 1 1/2 minutes).
Note: Be careful to use a NEW disk. If you use a disk that has data on it, this
procedure will erase the data.
Note : Pre-formatted IBM double sided, double density disks (720kb) do not need to be
initialized with this procedure. If you want to boot up the machine with the pre-formatted
disk, be sure to copy the following files onto this disk. If you initialize a disk with the
procedure above ,the files below are automatically saved onto the disk.
COND.DAT
OFFSET.DAT
STRING.DAT
