Wire EDM Machine Operation Chapter 15
Copyright November, 98 Page 15-8 Sodick Inc.
NC PROGRAM: When ON, it will show the NC program in the upper left corner of the
screen as it graphs the program.
MANUAL SCALE: When OFF, the control automatically scales the size of the picture
to fit on the screen, usually OFF.
When ON, you must define the size of picture you want on the screen using the XY MIN,
MAX parameters below this parameter.
