SolaX Power X1-Hybrid G4 Series User Manual

Advance settings
Ø
All advanced settings can be set here, such as battery, grid, off-grid, etc..
"Advanced" setting is generally customization and resetting for battery
and grid . Each part has lower level parts.
Please contact your installer or factory and enter the installer password.
* Please note that when the inverter DSP communication fails, all
advanced settings will be hidden.
DSP-COMM failed
>Battery
Advanced
>Battery Awaken
Charger
NO
82
83
Setting
Setting
Safety Code
Meter/CT Settings
Grid Parameters
Self Test
LVRT Function
Shadow Fix
X1-Matebox Setting
Pu Function
Modbus
Export Control
Power Factor
Advanced settings
Advance Password
DRM Function
Reset
Power limit
Main Breaker Limit
a)
b)
c)
d)
e)
f )
g)
h)
i)
j)
k)
l)
m)
n)
o)
p)
Safety Code
Grid Parameters
Advanced
>
a) Safety Code
User can set safety standard according to different countries and grid tied
. There are now 1 standards to choose from. (The here may be changes in
the future ,please refer to the screen display)
Item
1
Country
ARN 4105
Standard
German
OverVoltage_L1
UnderFreq_L1
UnderVoltage_L1
Vac 10min Avg
OverVoltage_L2
OverFreq_L2
UnderVoltage_L2
OverFreq_L1
UnderFreq_L2
UnderFreq_L2
Tovp_L1
Tuvp_L1
Tovp_L2
Tofp_L1
OverFreq_L2
Tuvp_L2
Grid Parameters
Tofp_L2
Reconnection Time
Tufp_Fast
Checking Time
OFPL_StartPoint
OFPL_SetRate
OFPL_DelayTime
W(Gra)
UFPL_StartPoint
UFPL_SetRate
UFPL_DelayTime
