97
Operation on LCD
NOTICE!
• The inverter cannot be connected to the grid before the safety code is correctly set. If
there is any doubt about your safety code where the inverter installed, please consult
your dealer or SolaX service for details.
• Different safety code may have different configuration options.
• When you select safety code CEI 0-21, there will be additional Self Test option for
setting under the path of Menu>Setting>Advance Setting.
• When you selelct safey code AS4777, there will be additional AS4777
Setting option for General Control and Export Control under the path of
Menu>Setting>Advance Setting.
Setting Grid parameters
The default value is the specified value under the current safety regulations. The contents
will be displayed according to the requirements of local laws and regulations. Please refer
to the actual contents displayed on the LCD screen on the inverter.
====Grid Parameters====
>Overvoltage
Undervoltage
OverFreq_L1
Please select Australia Region A/B/C in complicance with AS 4777. Only after the safety
code setting is completed, some designated parameters in the inverter system will take
effect according to the corresponding safety regulations.
Region Australia A Australia B Australia C New Zealand
Standarad
Code Name
AS4777_2022
_A
AS4777_2022
_B
AS4777_2022
_C
New Zealand
Setting
Range
OV-G-V 265 V 265 V 265 V 265 V
230-300
V
OV-GV1-T 1.5 s 1.5 s 1.5 s 1.5 s
OV-G-V2 275 V 275 V 275 V 275 V
230-300
V
OV-GV2-T 0.1 s 0.1 s 0.1 s 0.1 s
UN-G-V1 180 V 180 V 180 V 180 V
40-230
V
UNGV1-T 10 s 10 s 10 s 10 s
UN-G-V2 70 V 70 V 70 V 70 V
40-230
V
UNGV2-T 1.5 s 1.5 s 1.5 s 1.5 s
To Next Page
