2.7 Working Mode
Six working modes are available for you to choose in on-grid status, i.e Self use, Feed-
in priority, Backup, Peak shaving, TOU and Manual. You can choose the working modes
according to your lifestyle and environment.
When the power supply from the electric power company is stopped due to a power
outage, it automatically switches to EPS mode and connects to the distribution board for a
specific load, thereby providing power to important electrical appliances.
For how to set the working mode, please refer to the section "10.7.1 User Setting".
2.7.1 Self-use Mode (Priority: Loads > Battery > Grid)
The self-use mode is suitable for areas with low feed-in subsidies and high electricity
prices. The power of PV will supply the loads first, and the surplus power will charge the
battery, then the remaining power will feed into the grid.
Chag rin g Stan db y
Disc harging
Pu rchase electricity Sell electricity
Self use
Self-use Mode
(Assum in g p ea k po w er f rom 7 : 00 to 23: 00)
Id ea : Ta k e less electricity from th e g rid
Allowed d isch a rg ing p erio dForced ch a rg in g time
7:0 0
PV an d b attery po w er th e lo a d
Charge th e b attery
PV p owers th e lo ad
Load p ower cu rv e
18 :00 23: 00
Oth erOth er
Power
Time Line
Chag rin g Stan db y Discha rg in g
Oth er
Self use
Purc hase
ele c tric ity
Battery
status
Battery
SO C
Pu rchase
status
Time
settin g
Th e g rid su pp lies p o wer to th e
load an d ch a rg es th e b a tter y .
PV an d b attery
pow er load
Su rp lu s w ill b e
so ld to the utility
PV input power
Figure 2-10 Self-use mode
NOTICE!
• Set the export control according to the safety code.
Table 2-5 Description of self-use mode
Time period Inverter working status
Forced charging
period
• Charge the battery firstly untill the battery SOC reaches the
specified Charge battery to value. You can configure the
inverter to either draw power from the grid or not.
