Page #30 background image
22
System Overview
Table 3-9 Introduction to System Devices
Device Description
X3-ULTRA series (the
device covered in
this manual)
The X3-ULTRA series inverter photovoltaic storage inverter.
PV modules PV panel works in MPPT mode. The maximum number of PV string
per MPPT tracker is two for X3-ULT-15K, 19.9K and 20K inverter and
three for X3-ULT-15KP, 20KP, 25K and 30K inverter.
Battery The series inverter should be coupled a lithium-ion battery. The
battery communicates with the inverter via BMS and must comply
with the specifications of the regulations.
Meter/CT The meter/CT is used by the inverter for import / export or
consumption readings, and manages the battery charge / discharge
accordingly for smart energy management applications. The X3-
ULTRA series inverter supports wireless meter solution.
Adapter Box
(supported)
With SolaX Adapter Box, you can connect the smart grid heat pump
to the energy storage systems, realizing direct control of the heat
pump through inverter. Please refer to "15.2 Adapter Box Application"
for specific wiring and setting.
Datahub (supported) SolaX DataHub 1000 is a professional device that helps monitor and
manage your site with multiple inverters. Its power control functions
enable the system to comply with local grids. Please refer to "15.4
Datahub Application" for specific wiring and setting.
EV Charger
(supported)
X3-ULTRA series inverter can communicate with SolaX EV-Charger
to form an intelligent photovoltaic, storage and EV charging energy
system, thus maximizing the utilization of photovoltaic energy.
Please refer to "15.3 EV-Charger Application" for specific wiring and
setting.
Generator
(supported)
The generator guarantees a reliable supply in industrial plants,
backup systems and off-grid communities. SolaX PV-Genset solution
ensures optimum interaction between the photovoltaics and diesel
generator, which saves fuel, lowers energy costs and ensures a
stable and reliable power supply. Please refer to "15.1 Generator
Application" for specific wiring and setting.
Grid 400 V / 230 V and 380 V / 220 V grid are supported.
SolaX Cloud SolaX Cloud is an intelligent, multifunctional monitoring platform
that can be accessed either remotely or through a hard wired
connection. With the SolaX Cloud, the operators and installers can
always view key and up to date.
