Appendix
Setting for EV-Charger
Setting path: Menu>Setting>Advance Setting>Internal485
a. Select and enter Internal485 interface.
b. Select the EV Charger and set the Braud Rate and corresponding Address.
=====Internal485=====
>Function Control
EV Charger
>Braud Rate
9600
>EV Charger Addr:
70
=====Internal485===== =====Internal485=====
NOTICE!
• When two equipments need to be connected at the same time, the braud rate and
address of the two equipments shall be set to the same.
c. Check the connectiong status.
=====Internal485=====
>EV Charger COM STAT
Connected
d. You can enable Battery Charge EVC to allow the battery to discharge energy
to EV-Charger through setting path: Menu>Setting>Advance Setting>Battery
Charge EVC.
===Battery charge EVC===
>Function Control
Enable
NOTICE!
• Please refer to
X1/X3-EVC Series User Manual
for specific setting and wiring
connection on the EV-Charger.
