Mechanical Installation
6.1 Dimensions for mounting
Check the dimensions of the bracket before mounting and reserve sufficient space for heat
dissipation and installation of the whole system.
696
526
240
Figure 6-3 Dimensions 1 (Unit: mm)
Ø
348 348
14
18
333.5
348.5
379
14
300
619.5
531
696
305.6
526
Figure 6-4 Dimensions 2 (Unit: mm)
