22
Product Overview
Min ESC SOC: The minimum SOC of the battery to enter EPS mode. 30% by default, the
settable range: 15%-100%.
NOTICE!
When the battery supplies power to the load, the available capacity of the battery
decreases as the SOC decreases.
2.7.7 Manual Mode
This working mode is only for the after-sales team to do after-sales maintenance. It
includes Forced Discharge, Forced Charge and Stop chrg&dischrg. The system will
restore to the original working mode after six hours Manual mode set.
2.7.8 Export Control Function
Solar export control is a limit on the amount of energy your solar system that can export
into the grid. You have a set limit on how much energy you can export to the grid.
How Export Control works
CT/meter required
Correct setting of the limit value of Export Control through inverter. (For parallel
system, set on the master inverter)
PV
Load: 6 kW
2 kW
Meter
4 kW
2 kW
Grid
Inverter: 15 kW
2 kW
2 kW
2 kW
Figure 2-17 Zero export control with Phase Unbalance disabled
