JEA USER MANUAL
sollateksupport@sollatek.com I 13
3.3.3 EXTERNAL DEVICES
WARNING!
Separate as much as possible the data cables and cables carrying inductive load and power. Do Not run power and
signal cables together in the same conduit.
The JEA has an 8-way connector for adding external modules to further enhance the controller’s capabilities.
You can connect:
• Displays (FFD, FDM3)
• FFX expander port with plug-in modules
• GMC4 connectivity device
• programming device (SPPO3)
Sollatek provides a connection cable for all devices which connect to the JEA to make connecting quick and easy.
1. Plug the 8-way connector of the connecting cable into the port on the rear of the JEA.
Note: The connector will only fit into the port in one orientation.
2. Plug the other end of the connecting cable into the other device (refer to the device manual for port type and location).
Connecting
Device
