3
Contents
Overview RTS options 8
Compatibility, Motor-Power supply-sensors 9
Power connections: Applications with RTS integrated motors 11
Basic
Programming and setting of RTS motors 13
1 Connect the RTS transmitter to the motor 13
2 Check the motor rotation direction 13
3 Change motor rotation direction if needed 13
4 Place the blind in the desired UP position 13
5 Set the DOWN position 13
6 Set the UP position 14
7 Confirm end limit setting 14
8 Recording an RTS transmitter 14
Adjustments 15
Adjusting the DOWN limit 15
Adjusting the UP limit 15
Set blind mode: Roller or Venetian 16
Setting My position for NON TILT products 17
Setting My position for TILT products 17
Remove programmed My position 17
Wired RTS receivers, 24 VDC 18
24 V RTS Receivers, setting and programming 18
Setting from the RTS receiver 19
1 Set the RTS receiver in programming mode 19
2 Record the first RTS transmitter 19
Power 4 x 2,5 DC RTS 19
Setting from the RTS remote control 20
Set type of blind: Roll up or Tilt and li 21
Change the motor rotation direction 22
Sett the time for open and close movement 23
Modify the MY position, in Tilt & li mode 26
Modify the MY position, in Roll up mode 27
Remove a programmed MY-position 27
Activating the motor Run timer 28
Add a transmitter 29
Remove an assigned transmitter 29
