Sonim XP10 User Manual

8
YOUR SIM/SD CARD
YOUR SIM/SD CARD
INSERTING THE SIM CARDS
To access the SIM Card slots, use your Sonim
screwdriver to remove the battery door screw and then
remove the battery. The SIM card slots will be found
under the battery.
1. UNSCREW COVER
Use the Sonim screwdriver
provided in your box to
unscrew the battery cover
on the back of the phone.
2. REMOVE THE COVER
AND THE BATTERY
From the back of the
phone, insert your ngernail
into the back removal
notches at the bottom left
and right corner and gently
pull up to remove the back
cover.
Take the battery out.
3. OPEN THE SILVER
CLIPS
Slide (push to the left side)
and lift the silver clips over
the SIM slots.
4. INSERT SIM CARDS
Select the SIM card tray
in use. Insert the new SIM
card into the silver clip.
Close the silver clip by
sliding it to the right until
you hear a click to lock it
in place.
SIM 1
SIM 2
SIM CARD
The SIM (Subscribert Identity Module) card associates
your network services (for example, phone number, data
services, etc.) with your phone. The Sonim XP10 device
comes with Dual SIM card and Memory card trays.
Note: The XP10 does have two SIM slots and a SIM can
be inserted in either SIM slot. Due to carrier restrictions,
when two SIMs are present, only the SIM card in Slot 1 is
active.

Sonim XP10 Specifications

General

Display Size	5.5 inches
RAM	4GB
Storage	64GB
Waterproof	IP68
Dimensions	158.5 x 76.6 x 13.9 mm
Weight	260 g
Display Type	IPS LCD
Loudspeaker	Yes
3.5mm jack	Yes
Bluetooth	5.0
NFC	Yes
Radio	FM radio
Colors	Black
Camera (Front)	8 MP
Status	Available
SIM	Nano-SIM
Display Resolution	720 x 1440 pixels
Internal Memory	64GB
Selfie Camera	8 MP
WLAN	Wi-Fi 802.11 a/b/g/n/ac
Positioning	GPS, GLONASS, GALILEO
USB	USB Type-C
Features	Accelerometer, gyro, proximity, compass
Charging	Fast charging 18W
Expandable Storage	microSDXC
Wi-Fi	Wi-Fi 802.11 a/b/g/n/ac
Resolution	1440 x 720 pixels
Network	5G
