51
Subdisplay Menu List
Chapter 4 Menu Configuration and Detailed Settings
ND filter Clear F65RAW mode, HD mode:
Clear, 0.9, 1.2, 1.5, 1.8, Close,
Mainte
F65RAW-HFR mode:
Clear(HFR), Close, Mainte
Close: Filter closed
Mainte: Maintenance mode, with no
filter deployed (display only).
Switched using the VF menu.
Sensitivity (Cine mode: EI
value, Custom mode: dB
value)
Cine mode:
800EI
Custom mode:
0dB
Cine mode:
200EI, 250EI, 320EI, 400EI,
500EI, 640EI, 800EI, 1000EI,
1250EI, 1600EI, 2000EI,
2500EI, 3200EI
Custom mode:
–6dB, –3dB, 0dB, 3dB, 6dB,
9dB, 12dB
Color temperature 5500K 3200K, 4300K, 5500K
SDI2 Color When Base Setting/Color Space
is set to S-Gamut or Video
Setting/Gamma Category is set to
Special:
Display value: S-Gamut, F900,
709CS
Set value: S-Gamut, F900,
ITU-R BT.709
All other cases:
Off (display only)
Sets the color space for the image
output from the SDI OUT2 connector.
SDI2 LUT When Base Setting/Color Space
is set to S-Gamut or Video
Setting/Gamma Category is set to
Special:
709(800%), S-Log2,
HG8009G40, HG8009G33,
[User1], [User2], [User3],
[User4], [User5] to [User100]
All other cases:
Off (display only)
[User1] to [User100]: Name (max. 12
characters) of user MLUT read from
external memory.
Sets the LUT (look-up table) for the
image output from the SDI OUT2
connector.
Settings page 2
Reel number N/A 001 to 999, -- Displays the reel number of the
SRMemory card.
Fan operating mode Auto2 Auto1, Auto2, Min, Max Switches the operating mode of the fan.
For details on the fan operating mode,
see “3-3-9 Selecting the Fan Operating
Mode” (page 36).
Voltage (display only) N/A 0.1 V increments Displays the voltages of the 12 V and
24 V system power supplies.
Media remaining (display only) N/A 0 to 999min, --min, FULL, 16h to
999h
Displays the remaining recording time
for SR-R4 media.
File name 17 alphanumeric characters.
(Next): Displayed when not
recording or playing back.
Displays the name of the next file on the
SRMemory card that is to be recorded
(when not playing or recording) or the
name of the file that is currently being
played/recorded.
Time code (display only) N/A TCG, TCR, UBG, UBR, TM1, TM2 Displays the SR-R4 time code.
Settings page 3
ASSIGN button 1 Mag Off, Mag, Mag Position, Hi/Lo Key,
Fan Mode, Rec Review, Highlight
Clip Ind., SRMemory Eject
For details of each function, see “3-3-14
Assigning Functions to the ASSIGN
Buttons” (page 37).
ASSIGN button 2 Mag Position
ASSIGN button 3 Hi/Lo Key
ASSIGN button 4 Rec Review Off, Mag, Mag Position, Hi/Lo Key,
Fan Mode, Rec Review, Highlight
Clip Ind., SRMemory Eject, Bars
Item Default Set or display value Remarks
