Sony F65 - Non-Realtime Metadata

72
Metadata
Appendix
Cooke Protocol Lens metadata set
Non-realtime metadata
Raw White Code
Value
Uint16 2 E1.07 Code value of light from 90% reflectance chart at
suitable exposure (F65RAW/F65RAW-HFR mode
output only).
Monitoring Base
Curve
Label 16 E1.0B Label value, registered in SMPTE RP 224, indicating
the base curve when ASC CDL adjustment is added
for the monitor video on SDI-OUT1.
However, for user defined characteristics, this
indicates color gamuts based on the numbers as
follows.
User defined curve 6: S-Gamut
User defined curve 7: S-Gamut3
User defined curve 8: S-Gamut3.Cine
Monitoring
Descriptions
UTF8 String 12 E1.09 String indicating the combined SDI-OUT1 monitor
characteristic.
Example for each SDI1 Look Select setting:
• ACES-Proxy10: “ACES-Proxy10”
• Graded ACES: “Graded ACES”
• Look Profile: “SonyProf1: LC_709”
• S-Log3/S-Gamut3.Cine: “S-Log3/S-Gamut3.Cine”
On this unit, “based” is appended to the combined
characteristic string to indicate that video adjustment
using the ASC CDL function is possible.
Example: “SonyProf1: LC_709 based”
Item name Data type Length (bytes) Local tag Meaning
User Defined
Acquisition
Metadata
Set Key (UL) 16 – User Defined Acquisition Metadata Key
06.0E.2B.34.02.53.01.01.0C.02.01.01.7F.01.00.00
Length BER Length 4 – Cooke Protocol Lens metadata set length.
UDAM Set
Identifier
AUID 16 E0.00 Cooke Protocol Lens metadata set identifier.
Cooke Protocol
Calibration Type
UInt8 1 E2.03 Lens data distance unit.
0: mm
1: 0.1 inch
Cooke Protocol
Binary Metadata
Data Stream Variable E2.01 Lens position data in binary format defined by Cooke
/i protocol.
Cooke Protocol
User Metadata
Data Stream Variable E2.02 Cooke /i protocol user data.
Lens Attribute UTF8 String Variable 80.07 Lens serial number.
Item name Data type Length (bytes) Local tag Meaning
Slate1 Unit
Metadata
Set Key (UL) 1 – Local definition key (01) for the first packet.
Length 4-byte length 4 – Data length of first packet, excluding the Key and
Length attributes.
Description UTF8 String Variable
(128 max.)
01.01 Comment area.
Project UTF8 String Variable
(24 max.)
01.02 Name of project.
Director Name UTF8 String Variable
(24 max.)
01.03 Name of director.
Item name Data type Length (bytes) Local tag Meaning
