63
VF Menu List
Chapter 4 Menu Configuration and Detailed Settings
<Status>
Status indicator
display item
settings
System Format Off On, Off Turns the signal format indicator On/Off.
FPS Off On, Off Turns the FPS value indicator On/Off.
ND Filter Off On, Off Turns the ND filter indicator On/Off.
Color Temperature Off On, Off Turns the color temperature indicator
On/Off.
EI/Master Gain Off On, Off Turns the EI value indicator On/Off.
Shutter Off On, Off Turns the shutter operation status
indicator On/Off.
SDI1 Look Off On, Off Turns the SDI1 Look setting indicator
On/Off.
SDI2 Look Off On, Off Turns the SDI2 Look setting indicator
On/Off.
Battery DC IN 12V Off On, Off Turns the 12 V supply voltage indicator
On/Off.
Battery DC IN 24V Off On, Off Turns the 24V supply voltage indicator
On/Off.
Media Remain/File
Name
Off On, Off Turns the media remaining and file name
indicator On/Off.
Time Code Off On, Off Turns the time code indicator On/Off.
Message On On, Off Turns the message indicator On/Off.
Highlight Clip
Indicator
On On, Off Turns the Highlight Clip Indicator
function On/Off.
Rec On On, Off Turns the recording indicator On/Off.
Lens Off On, Off Turns the focus, iris, and zoom position
indicators for the attached lens On/Off.
<Marker>
Marker indicator
display item
settings
Center Off On, Off Turns the center marker On/Off.
Effective Off On, Off Turns the effective pixel area marker
indicator On/Off.
Aspect Ratio 2.39:1 2.39:1, 2.35:1, 1.90:1,
1.85:1, 1.78:1, 1.66:1,
1.33:1, Variable
Sets the aspect ratio when Effective is
set to On.
Displays “Variable (Width/Height:1)” ratio
when Aspect Ratio is set to Variable.
Width 960 960 to 1920 Specifies the width of the effective pixel
area when Aspect Ratio is set to
Variable.
Height 540 540 to 1080 Specifies the height of the effective pixel
area when Aspect Ratio is set to
Variable.
Mask Off On, Off Enables/disables darkening of image
outside the selected Aspect Marker.
Level 2 0 to 4 Sets the darkness level of the image
outside the selected Aspect Marker.
<Cursor>
Cursor indicator
display item
settings
Box Off On, Off Turns the box cursor On/Off.
Aspect Ratio Variable
(1.78:1)
-- Displays “width/height:1.”
Horizontal 0 –958 to 958 Specifies the horizontal position from the
center.
Vertical 0 –538 to 538 Specifies the vertical position from the
center.
Width 960 320 to 1920 Specifies the width of the box cursor.
Height 540 180 to 1080 Specifies the height of the box cursor.
Page Configuration
item
Default Settings Remarks
