– 13 –
3-7. DISC TABLE
3-8. SUB CHASSIS
1
Screw (BV3x8)
2
Screw (BV3x8)
3
Holder (MG) assembly
4
Pull the disc table
3
Two step screws
4
Two insulators
5
Sub chassis
Part
A
Part
A
Part
A
1
Two step screws
2
Two insulators
Take care so that the part
A
may be right
position when installing.
