• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
CND : Canadian model
EE : East European model
MY : Malaysia model
SP : Singapore model
JE : Tourist model
HK : Hong Kong model
AR : Argentine model
AUS : Australian model
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
SECTION 9
ELECTRICAL PARTS LIST
Note:
When indicating parts by reference
number, please include the board
name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AUDIO
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
* A-4414-818-A AUDIO BOARD, COMPLETE (AEP,UK,EE)
*********************
* A-4414-821-A AUDIO BOARD, COMPLETE
*********************
(MY,SP,JE,HK,AR,AUS)
* A-4414-824-A AUDIO BOARD, COMPLETE (US,CND)
*********************
< CAPACITOR >
C701 1-126-163-11 ELECT 4.7uF 20% 50V
C702 1-126-163-11 ELECT 4.7uF 20% 50V
C703 1-126-163-11 ELECT 4.7uF 20% 50V
C704 1-126-163-11 ELECT 4.7uF 20% 50V
C705 1-126-163-11 ELECT 4.7uF 20% 50V
C706 1-136-165-00 FILM 0.1uF 5% 50V
C707 1-124-464-11 ELECT 0.22uF 20% 50V
C708 1-130-473-00 MYLAR 0.0015uF 5% 50V
C709 1-126-160-11 ELECT 1uF 20% 50V
C712 1-162-294-31 CERAMIC 0.001uF 10% 50V
C713 1-124-589-11 ELECT 47uF 20% 16V
C714 1-136-165-00 FILM 0.1uF 5% 50V
C715 1-136-165-00 FILM 0.1uF 5% 50V
C716 1-124-261-00 ELECT 10uF 20% 50V
C717 1-126-163-11 ELECT 4.7uF 20% 50V
C718 1-162-290-31 CERAMIC 470PF 10% 50V
C719 1-124-589-11 ELECT 47uF 20% 16V
C720 1-124-589-11 ELECT 47uF 20% 16V
C731 1-130-475-00 MYLAR 0.0022uF 5% 50V
C743 1-124-589-11 ELECT 47uF 20% 16V
C751 1-126-163-11 ELECT 4.7uF 20% 50V
C752 1-126-163-11 ELECT 4.7uF 20% 50V
C753 1-126-163-11 ELECT 4.7uF 20% 50V
C754 1-126-163-11 ELECT 4.7uF 20% 50V
C755 1-126-163-11 ELECT 4.7uF 20% 50V
C756 1-136-165-00 FILM 0.1uF 5% 50V
C757 1-124-464-11 ELECT 0.22uF 20% 50V
C758 1-130-473-00 MYLAR 0.0015uF 5% 50V
C759 1-126-160-11 ELECT 1uF 20% 50V
C762 1-124-261-00 ELECT 10uF 20% 50V
C763 1-130-477-00 MYLAR 0.0033uF 5% 50V
C764 1-136-165-00 FILM 0.1uF 5% 50V
C765 1-136-165-00 FILM 0.1uF 5% 50V
C766 1-124-261-00 ELECT 10uF 20% 50V
C767 1-126-163-11 ELECT 4.7uF 20% 50V
C768 1-162-290-31 CERAMIC 470PF 10% 50V
C769 1-162-294-31 CERAMIC 0.001uF 10% 50V
C781 1-130-475-00 MYLAR 0.0022uF 5% 50V
C1501 1-124-589-11 ELECT 47uF 20% 16V
(AEP,UK,EE)
C1502 1-164-159-11 CERAMIC 0.1uF 50V
(AEP,UK,EE)
C1503 1-126-157-11 ELECT 10uF 20% 16V
(AEP,UK,EE)
C1504 1-162-291-31 CERAMIC 560PF 10% 50V
(AEP,UK,EE)
C1505 1-126-157-11 ELECT 10uF 20% 16V
(AEP,UK,EE)
C1506 1-124-257-00 ELECT 2.2uF 20% 50V
(AEP,UK,EE)
C1507 1-102-518-11 CERAMIC 33PF 5% 50V
(AEP,UK,EE)
C1508 1-162-288-31 CERAMIC 330PF 10% 50V
(AEP,UK,EE)
C1509 1-102-518-11 CERAMIC 33PF 5% 50V
(AEP,UK,EE)
C1510 1-162-306-11 CERAMIC 0.01uF 20% 16V
(AEP,UK,EE)
C1511 1-162-291-31 CERAMIC 560PF 10% 50V
(AEP,UK,EE)
C1512 1-162-306-11 CERAMIC 0.01uF 20% 16V
(AEP,UK,EE)
C1513 1-162-301-11 CERAMIC 0.0015uF 20% 16V
(AEP,UK,EE)
C1515 1-162-600-11 CERAMIC 0.0047uF 20% 16V
(AEP,UK,EE)
< CONNECTOR >
CN701 1-779-819-11 CONNECTOR, BOARD TO BOARD 14P
CN702 1-779-819-11 CONNECTOR, BOARD TO BOARD 14P
< DIODE >
D701 8-719-911-19 DIODE 1SS119-25
D1501 8-719-911-19 DIODE 1SS119-25 (AEP,UK,EE)
< IC >
IC701 8-759-439-30 IC M62428FP
IC702 8-759-634-51 IC M5218AP
IC1500 8-759-450-87 IC BU1922F (AEP,UK,EE)
IC1501 8-759-636-55 IC M5218AFP (AEP,UK,EE)
To Next Page
