– 95 –
48 BD SQCLK O Sub-code Q data reading clock signal output to the CXD2507AQ (IC103)
49 BD CLOCK O Serial data clock signal output to the CXD2507AQ (IC103)
50 BD DATA O Serial data output to the CXD2507AQ (IC103)
51 XLT O Serial data latch pulse signal output to the CXD2507AQ (IC103)
52 PRGL (DF. LAT) O Serial data latch pulse signal output to the PCM1710U (IC104)
53 SENCE I Internal status (SENSE) signal input from the CXD2507AQ (IC103)
54 ADJ I Test mode input terminal “H’: normal (fixed at “H” in this set)
55 IN-SW I Disc tray close complete signal input terminal “L”: Completed
56 OUT-SW I Disc tray open complete signal input terminal “L” Completed
57 LOAD-OUT O Disc tray loading out signal output to the motor driver (IC801)
58 LOAD-IN O Disc tray loading in signal output to the motor driver (IC801)
59 FOCUS-SW O Focus gain selection switch signal output terminal “L”: normal “H”: down
60 BD-REST O BD block reset signal output terminal “L”: reset
61 CD-POWER O CD power on/off signal output to the CD power regulator (Q561, 562)
62 ST-POWER O ST power on/off signal output terminal Not used (open)
63 D. IN. SELECT O Optical/CD select signal output terminal “H”: optical “L”: CD
64, 65 — — Not used
66 LED-CD. DISC O CD INDICATOR LED (D908) drive signal output terminal
67 LED-MD. DISC O MD INDICATOR LED (D905) drive signal output terminal
68 LED-MD. REC O r LED (D904) drive signal output terminal
69 LED-CD. PAUSE O P (CD) LED (D907) drive signal output terminal
70 LED-CD. PLAY O ( (CD) LED (D906) drive signal output terminal
71 VSS — Ground terminal
72 LED-MD. PAUSE O P (MD) LED (D903) drive signal output terminal
73 LED-MD. PLAY O ( (MD) LED (D902) drive signal output terminal
74 DBFB O DBFB on/off signal output terminal “L”: on
75 RECOUT. MUTE O Rec mute (tape) signal output terminal “L”: mute
76 MUTE O Mute signal output terminal
77 ATT/6DB O Tape input level attenuate signal output terminal
78 SOUND/IC DATA O Graphic equalizer data signal output to the M62428FP (IC701)
79 SOUND/IC CLOCK O Graphic equalizer data clock signal output to the M62428FP (IC701)
80 SOUND/IC LAT O Graphic equalizer data latch pulse signal output to the M62428FP (IC701)
81 (GND) — Ground terminal
82 ST STEREO I Stereo detection signal input from the tuner
83 ST TUNED I Tuned detection signal input from the tuner
84 ST DATA-IN I Data signal input from the tuner
85 ST DATA-OUT O Data signal output to the tuner
86 ST CLOCK O Data transfer clock signal output to the tuner
87 ST CE O Chip enable signal output to the tuner
88 ST MUTE O Mute signal output to the tuner
89 FM/AM SELECT O FM/AM select signal output Not used (open)
90 SIRCUS I Remote control signal input from the remote control receiver (IC902)
91 — — Not used (open)
92 — — Connecting to ground
93 FAN SPEED O Fan speed control signal output terminal Not used (open)
94 FAN STOP O Fan on/off signal output terminal Not used (open)
95 to 99 — — Connecting to ground
100 BACKUP I System reset signal input from the reset signal generator (IC602)
