Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-VX777
MAIN
R164 1-216-845-11 METAL CHIP 100K 5% 1/16W
R165 1-216-833-11 METAL CHIP 10K 5% 1/16W
R166 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R171 1-216-834-11 METAL CHIP 12K 5% 1/16W
R172 1-216-833-11 METAL CHIP 10K 5% 1/16W
R173 1-216-833-11 METAL CHIP 10K 5% 1/16W
R175 1-216-833-11 METAL CHIP 10K 5% 1/16W
R181 1-216-839-11 METAL CHIP 33K 5% 1/16W
R189 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R205 1-216-833-11 METAL CHIP 10K 5% 1/16W
R301 1-216-836-11 METAL CHIP 18K 5% 1/16W
R302 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R303 1-216-809-11 METAL CHIP 100 5% 1/16W
R304 1-216-809-11 METAL CHIP 100 5% 1/16W
R305 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R306 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R307 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R308 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R309 1-216-837-11 METAL CHIP 22K 5% 1/16W
R311 1-216-857-11 METAL CHIP 1M 5% 1/16W
R312 1-218-745-11 RES-CHIP 160K 5% 1/16W
R313 1-216-845-11 METAL CHIP 100K 5% 1/16W
R315 1-216-833-11 METAL CHIP 10K 5% 1/16W
R316 1-216-839-11 METAL CHIP 33K 5% 1/16W
R317 1-216-833-11 METAL CHIP 10K 5% 1/16W
R318 1-216-833-11 METAL CHIP 10K 5% 1/16W
R319 1-216-852-11 METAL CHIP 390K 5% 1/16W
R320 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R321 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R331 1-216-846-11 METAL CHIP 120K 5% 1/16W
R332 1-216-809-11 METAL CHIP 100 5% 1/16W
R333 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R334 1-218-332-11 RES-CHIP 130K 5% 1/16W
R335 1-216-813-11 METAL CHIP 220 5% 1/16W
R336 1-216-846-11 METAL CHIP 120K 5% 1/16W
R337 1-216-813-11 METAL CHIP 220 5% 1/16W
R338 1-216-837-11 METAL CHIP 22K 5% 1/16W
R339 1-216-834-11 METAL CHIP 12K 5% 1/16W
R340 1-216-850-11 METAL CHIP 270K 5% 1/16W
R341 1-216-813-11 METAL CHIP 220 5% 1/16W
R342 1-216-834-11 METAL CHIP 12K 5% 1/16W
0R343 1-219-787-17 FUSIBLE 5.6 5% 1/4W
0R344 1-219-787-17 FUSIBLE 5.6 5% 1/4W
R345 1-216-836-11 METAL CHIP 18K 5% 1/16W
R346 1-216-836-11 METAL CHIP 18K 5% 1/16W
R347 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R351 1-216-836-11 METAL CHIP 18K 5% 1/16W
R352 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R353 1-216-809-11 METAL CHIP 100 5% 1/16W
R354 1-216-809-11 METAL CHIP 100 5% 1/16W
R355 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R356 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R357 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R358 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R359 1-216-839-11 METAL CHIP 33K 5% 1/16W
R360 1-216-819-11 METAL CHIP 680 5% 1/16W
R361 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R363 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R364 1-216-819-11 METAL CHIP 680 5% 1/16W
R366 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R367 1-216-841-11 METAL CHIP 47K 5% 1/16W
R368 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R369 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R371 1-216-841-11 METAL CHIP 47K 5% 1/16W
R372 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R373 1-216-821-11 METAL CHIP 1K 5% 1/16W
R374 1-216-841-11 METAL CHIP 47K 5% 1/16W
R375 1-218-296-11 RES-CHIP 75K 5% 1/16W
R376 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R377 1-216-841-11 METAL CHIP 47K 5% 1/16W
R378 1-218-296-11 RES-CHIP 75K 5% 1/16W
R379 1-216-821-11 METAL CHIP 1K 5% 1/16W
R381 1-216-846-11 METAL CHIP 120K 5% 1/16W
R382 1-216-809-11 METAL CHIP 100 5% 1/16W
R383 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R384 1-218-332-11 RES-CHIP 130K 5% 1/16W
R386 1-216-846-11 METAL CHIP 120K 5% 1/16W
R387 1-216-813-11 METAL CHIP 220 5% 1/16W
R388 1-216-837-11 METAL CHIP 22K 5% 1/16W
R389 1-216-834-11 METAL CHIP 12K 5% 1/16W
R390 1-216-850-11 METAL CHIP 270K 5% 1/16W
R391 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R392 1-216-834-11 METAL CHIP 12K 5% 1/16W
R393 1-216-837-11 METAL CHIP 22K 5% 1/16W
R394 1-216-813-11 METAL CHIP 220 5% 1/16W
R396 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R397 1-216-821-11 METAL CHIP 1K 5% 1/16W
R399 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R500 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R501 1-216-837-11 METAL CHIP 22K 5% 1/16W
R502 1-216-833-11 METAL CHIP 10K 5% 1/16W
R503 1-216-833-11 METAL CHIP 10K 5% 1/16W
R504 1-216-833-11 METAL CHIP 10K 5% 1/16W
R507 1-216-833-11 METAL CHIP 10K 5% 1/16W
R508 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R509 1-216-833-11 METAL CHIP 10K 5% 1/16W
R510 1-216-845-11 METAL CHIP 100K 5% 1/16W
R511 1-216-851-11 METAL CHIP 330K 5% 1/16W
R513 1-216-864-91 SHORT 0
R515 1-216-833-11 METAL CHIP 10K 5% 1/16W
R516 1-216-833-11 METAL CHIP 10K 5% 1/16W
R517 1-216-833-11 METAL CHIP 10K 5% 1/16W
R518 1-216-833-11 METAL CHIP 10K 5% 1/16W
R520 1-216-833-11 METAL CHIP 10K 5% 1/16W
R522 1-216-819-11 METAL CHIP 680 5% 1/16W
R523 1-216-821-11 METAL CHIP 1K 5% 1/16W
R523 1-216-864-91 SHORT 0 (EXCEPT EA)
R529 1-216-809-11 METAL CHIP 100 5% 1/16W
R530 1-216-809-11 METAL CHIP 100 5% 1/16W
R532 1-216-841-11 METAL CHIP 47K 5% 1/16W
R541 1-216-841-11 METAL CHIP 47K 5% 1/16W
R543 1-216-809-11 METAL CHIP 100 5% 1/16W
R544 1-216-809-11 METAL CHIP 100 5% 1/16W
R545 1-216-809-11 METAL CHIP 100 5% 1/16W
R546 1-216-809-11 METAL CHIP 100 5% 1/16W
R547 1-216-809-11 METAL CHIP 100 5% 1/16W
R548 1-216-809-11 METAL CHIP 100 5% 1/16W
R549 1-216-809-11 METAL CHIP 100 5% 1/16W
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
