Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-VX777
MAIN
R553 1-216-833-11 METAL CHIP 10K 5% 1/16W
R556 1-216-809-11 METAL CHIP 100 5% 1/16W
R557 1-216-809-11 METAL CHIP 100 5% 1/16W
R570 1-216-809-11 METAL CHIP 100 5% 1/16W
R573 1-216-833-11 METAL CHIP 10K 5% 1/16W
R574 1-216-833-11 METAL CHIP 10K 5% 1/16W
R575 1-216-833-11 METAL CHIP 10K 5% 1/16W
R576 1-216-841-11 METAL CHIP 47K 5% 1/16W
R577 1-216-841-11 METAL CHIP 47K 5% 1/16W
R578 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R579 1-216-817-11 METAL CHIP 470 5% 1/16W
R582 1-216-833-11 METAL CHIP 10K 5% 1/16W
R583 1-216-809-11 METAL CHIP 100 5% 1/16W
R584 1-216-809-11 METAL CHIP 100 5% 1/16W
R585 1-216-833-11 METAL CHIP 10K 5% 1/16W
R588 1-216-809-11 METAL CHIP 100 5% 1/16W
R589 1-216-809-11 METAL CHIP 100 5% 1/16W
R590 1-216-809-11 METAL CHIP 100 5% 1/16W
R591 1-216-809-11 METAL CHIP 100 5% 1/16W
R592 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R593 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R804 1-216-841-11 METAL CHIP 47K 5% 1/16W
R821 1-216-841-11 METAL CHIP 47K 5% 1/16W
R822 1-216-842-11 METAL CHIP 56K 5% 1/16W
R823 1-216-833-11 METAL CHIP 10K 5% 1/16W
R824 1-216-841-11 METAL CHIP 47K 5% 1/16W
R825 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R826 1-216-839-11 METAL CHIP 33K 5% 1/16W
R827 1-216-837-11 METAL CHIP 22K 5% 1/16W
R829 1-216-837-11 METAL CHIP 22K 5% 1/16W
R830 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R831 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R841 1-216-837-11 METAL CHIP 22K 5% 1/16W
R842 1-216-837-11 METAL CHIP 22K 5% 1/16W
R843 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R844 1-216-845-11 METAL CHIP 100K 5% 1/16W
R845 1-216-857-11 METAL CHIP 1M 5% 1/16W
R854 1-216-841-11 METAL CHIP 47K 5% 1/16W
R861 1-216-821-11 METAL CHIP 1K 5% 1/16W
R862 1-216-833-11 METAL CHIP 10K 5% 1/16W
R863 1-216-841-11 METAL CHIP 47K 5% 1/16W
R864 1-216-821-11 METAL CHIP 1K 5% 1/16W
R865 1-216-821-11 METAL CHIP 1K 5% 1/16W
R866 1-216-806-11 RES-CHIP 56 5% 1/16W
R868 1-215-891-11 METAL OXIDE 680 5% 2W
R869 1-215-891-11 METAL OXIDE 680 5% 2W
R891 1-216-833-11 METAL CHIP 10K 5% 1/16W
R892 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R893 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R895 1-216-864-91 SHORT 0
0R901 1-249-405-11 CARBON 100 5% 1/4W F
R903 1-249-405-11 CARBON 100 5% 1/4W F
R911 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R912 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R914 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R915 1-219-591-11 FUSIBLE 0.1 5% 1/2W
R916 1-219-119-11 FUSIBLE 0.1 5% 1/4W
R966 1-216-806-11 RES-CHIP 56 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB41 1-234-575-11 ENCAPSULATED COMPONENT
< VARIABLE RESISTOR >
RV11 1-241-765-11 RES, ADJ, CARBON 22K
RV301 1-241-764-11 RES, ADJ, CARBON 10K
RV302 1-241-762-11 RES, ADJ, CARBON 2.2K
RV303 1-241-762-11 RES, ADJ, CARBON 2.2K
RV304 1-241-768-11 RES, ADJ, CARBON 220K
RV351 1-241-764-11 RES, ADJ, CARBON 10K
RV354 1-241-768-11 RES, ADJ, CARBON 220K
< RELAY >
RY801 1-755-372-11 RELAY
RY803 1-755-373-11 RELAY
< TRANSFORMER >
T11 1-435-792-11 TRANSFORMER, DISCRIMINATOR
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
< TERMINAL >
TM1 1-694-555-22 TERMINAL BOARD (4P)
TM801 1-694-635-12 TERMINAL BOARD (4P)
< VIBRATOR >
X51 1-760-549-31 VIBRATOR, CRYSTAL
X501 1-567-098-41 VIBRATOR, CRYSTAL
X502 1-781-107-21 VIBRATOR, SERAMIC
**************************************************************
1-680-265-11 MAINS TRANS BOARD
****************
< CAPACITOR >
C941 1-128-553-11 ELECT 220uF 20.00% 63V
< CONNECTOR >
CN973 1-564-321-00 PIN, CONNECTOR 2P (TH)
CN973 1-568-106-11 PIN, CONNECTOR 4P (EXCEPT TH)
CN977 1-564-528-11 PLUG, CONNECTOR 13P
< DIODE >
D977 8-719-024-99 DIODE 11ES2-NTA2B
< FUSE >
0F971 1-532-325-00 FUSE, GLASS TUBE (DIA.5) (6.3A/250V)
(EXCEPT TH)
0F974 1-532-325-00 FUSE, GLASS TUBE (DIA.5) (6.3A/250V)
0F975 1-532-325-00 FUSE, GLASS TUBE (DIA.5) (6.3A/250V)
0F976 1-533-949-31 TIME LUG (DIA.5) (T8A/250V)
0F977 1-533-949-31 TIME LUG (DIA.5) (T8A/250V)
< RESISTOR >
0R941 1-217-637-00 FUSIBLE 1 5% 1/4W
0R944 1-217-641-00 FUSIBLE 4.7 5% 1/4W
0R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W
0R953 1-219-120-11 FUSIBLE 0.15 5% 1/4W
**************************************************************
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
