77
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-VX777
PAD SWITCHMOTOR
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
1-675-910-14 MOTOR BOARD
**********
< CAPACITOR >
C721 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< CONNECTOR >
CN721 1-770-516-31 CONNECTOR, FFC 8P
CN722 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE)4P
< SWITCH >
S701 1-771-822-11 SWITCH, LEVER (SLIDE)
**************************************************************
A-2007-995-A PAD SWITCH BOARD, COMPLETE (IA)
******************************
A-4476-103-A PAD SWITCH BOARD, COMPLETE (E,EA,SP)
***********************************
A-4476-627-A PAD SWITCH BOARD, COMPLETE (TH)
******************************
4-231-581-01 HOLDER (FL)(E,EA,SP,IA)
< CAPACITOR >
C751 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C752 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< DIODE >
D751 8-719-063-93 DIODE SLR325VC-N-T32
D752 8-719-063-93 DIODE SLR325VC-N-T32
< TRANSISTOR >
Q751 8-729-900-80 TRANSISTOR DTC114ES
Q752 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R750 1-249-410-11 CARBON 270 5% 1/4W F
R751 1-249-415-11 CARBON 680 5% 1/4W
R752 1-249-411-11 CARBON 330 5% 1/4W
R754 1-249-410-11 CARBON 270 5% 1/4W F
R755 1-249-413-11 CARBON 470 5% 1/4W F
R756 1-249-414-11 CARBON 560 5% 1/4W F
R757 1-249-416-11 CARBON 820 5% 1/4W F
R758 1-249-417-11 CARBON 1K 5% 1/4W F
R759 1-249-418-11 CARBON 1.2K 5% 1/4W F
R760 1-249-419-11 CARBON 1.5K 5% 1/4W F
R761 1-249-421-11 CARBON 2.2K 5% 1/4W F
R762 1-249-422-11 CARBON 2.7K 5% 1/4W F
R763 1-249-424-11 CARBON 3.9K 5% 1/4W F
R764 1-249-426-11 CARBON 5.6K 5% 1/4W
R765 1-249-428-11 CARBON 8.2K 5% 1/4W F
R766 1-249-431-11 CARBON 15K 5% 1/4W
R767 1-249-434-11 CARBON 27K 5% 1/4W
R768 1-249-410-11 CARBON 270 5% 1/4W F
R769 1-249-413-11 CARBON 470 5% 1/4W F
R770 1-249-414-11 CARBON 560 5% 1/4W F
R771 1-249-416-11 CARBON 820 5% 1/4W F
R772 1-249-417-11 CARBON 1K 5% 1/4W F
R773 1-249-418-11 CARBON 1.2K 5% 1/4W F
R774 1-249-419-11 CARBON 1.5K 5% 1/4W F
R775 1-249-421-11 CARBON 2.2K 5% 1/4W F
R776 1-249-422-11 CARBON 2.7K 5% 1/4W F
R777 1-249-424-11 CARBON 3.9K 5% 1/4W F
R778 1-249-426-11 CARBON 5.6K 5% 1/4W
R779 1-249-428-11 CARBON 8.2K 5% 1/4W F
R780 1-249-431-11 CARBON 15K 5% 1/4W
R781 1-249-439-11 CARBON 68K 5% 1/4W
R790 1-249-434-11 CARBON 27K 5% 1/4W
< SWITCH >
S751 1-476-504-11 ENCODER-ROTARY (VOLUME)
S752 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S753 1-771-410-21 SWITCH, TACTILE (b)
S754 1-771-410-21 SWITCH, TACTILE (B)
S755 1-771-410-21 SWITCH, TACTILE (SPEANA)
S756 1-771-410-21 SWITCH, TACTILE (EFFECT ON/OFF)
S757 1-771-410-21 SWITCH, TACTILE (GAME EQ)
S758 1-771-410-21 SWITCH, TACTILE (KARAOKE PON)
S759 1-771-410-21 SWITCH, TACTILE (PICTURE EFFECT)
S760 1-771-410-21 SWITCH, TACTILE (.)
S762 1-771-410-21 SWITCH, TACTILE (x)
S763 1-771-410-21 SWITCH, TACTILE (CD SYNC HI-DUB)
S764 1-771-410-21 SWITCH, TACTILE (REC PAUSE/START)
S765 1-771-410-21 SWITCH, TACTILE (>)
S766 1-771-410-21 SWITCH, TACTILE (M/+)
S767 1-771-410-21 SWITCH, TACTILE (m/–)
S768 1-771-410-21 SWITCH, TACTILE (TUNER MEMORY)
S769 1-771-410-21 SWITCH, TACTILE (FM MODE)
S770 1-771-410-21 SWITCH, TACTILE (DIRECTION)
S771 1-771-410-21 SWITCH, TACTILE (MUSIC EQ)
S772 1-771-410-21 SWITCH, TACTILE (MOVIE EQ)
S773 1-771-410-21 SWITCH, TACTILE (v)
S774 1-771-410-21 SWITCH, TACTILE (ENTER)
S775 1-771-410-21 SWITCH, TACTILE (V)
S776 1-771-410-21 SWITCH, TACTILE (P FILE)
S777 1-771-410-21 SWITCH, TACTILE (GROOVE)
S778 1-771-410-21 SWITCH, TACTILE (SURROUND)
S779 1-771-410-21 SWITCH, TACTILE (G)
S780 1-771-410-21 SWITCH, TACTILE (X)
S781 1-771-410-21 SWITCH, TACTILE (F-AMS)
**************************************************************
A-4476-616-A PANEL BOARD, COMPLETE (IA)
*************************
A-4476-133-A PANEL BOARD, COMPLETE (E,EA,SP)
******************************
A-4726-193-A PANEL BOARD, COMPLETE (TH)
*************************
< CAPACITOR >
C603 1-162-286-31 CERAMIC 220PF 10% 50V
C604 1-124-257-00 ELECT 2.2uF 20% 50V
C605 1-162-286-31 CERAMIC 220PF 10% 50V
C606 1-124-257-00 ELECT 2.2uF 20% 50V
C607 1-126-157-11 ELECT 10uF 20% 16V
C608 1-126-157-11 ELECT 10uF 20% 16V
