80
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-VX777
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
C581 1-126-967-11 ELECT 47uF 20.00% 50V(TH)
C591 1-136-165-00 FILM 0.1uF 5.00% 50V
C592 1-137-844-11 ELECT 2200uF 20% 42V
C596 1-137-849-11 ELECT 2200uF 20% 100V
C942 1-126-964-11 ELECT 10uF 20.00% 50V
C943 1-126-968-11 ELECT 100uF 20.00% 50V
< CONNECTOR >
CN502 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN503 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN504 1-506-468-11 PIN, CONNECTOR 3P
CN701 1-568-951-11 PIN, CONNECTOR 2P
< DIODE >
D501 8-719-911-19 DIODE 1SS133T-72
D502 8-719-911-19 DIODE 1SS133T-72
D503 8-719-947-70 DIODE MTZJ-T-72-18C
D504 8-719-947-70 DIODE MTZJ-T-72-18C
D541 8-719-500-60 DIODE D5SBA20
D543 8-719-510-68 DIODE D5SBA204101
D551 8-719-911-19 DIODE 1SS133T-72
D581 8-719-911-19 DIODE 1SS133T-72
D941 8-719-150-92 DIODE MTZJ-T-72-33D
< EARTH >
* EP501 1-537-738-21 TERMINAL, EARTH
< IC >
IC501 8-749-017-06 IC STK412-150
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q503 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q504 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q505 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q506 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q551 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q581 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q831 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q941 8-729-141-83 TRANSISTOR 2SB1094-LK
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W F
R502 1-249-438-11 CARBON 56K 5% 1/4W
R503 1-249-412-11 CARBON 390 5% 1/4W F
R504 1-249-438-11 CARBON 56K 5% 1/4W
R505 1-249-417-11 CARBON 1K 5% 1/4W F
R506 1-249-433-11 CARBON 22K 5% 1/4W
R507 1-249-441-11 CARBON 100K 5% 1/4W
0R508 1-208-603-11 METAL 0.1 20% 5W
R509 1-260-076-11 CARBON 10 5% 1/2W
0R510 1-208-603-11 METAL 0.1 20% 5W
0R511 1-212-881-11 FUSIBLE 100 5% 1/4W
0R512 1-202-972-61 FUSIBLE 1 5% 1/4W
R513 1-249-435-11 CARBON 33K 5% 1/4W
R514 1-249-421-11 CARBON 2.2K 5% 1/4W F
R515 1-249-433-11 CARBON 22K 5% 1/4W
R516 1-249-429-11 CARBON 10K 5% 1/4W
R517 1-249-421-11 CARBON 2.2K 5% 1/4W F
R518 1-249-435-11 CARBON 33K 5% 1/4W
R519 1-249-439-11 CARBON 68K 5% 1/4W
R520 1-215-872-11 METAL OXIDE 3.3K 5% 1W
R521 1-249-441-11 CARBON 100K 5% 1/4W
R522 1-249-441-11 CARBON 100K 5% 1/4W
R523 1-249-440-11 CARBON 82K 5% 1/4W
R524 1-215-872-11 METAL OXIDE 3.3K 5% 1W
R531 1-249-409-11 CARBON 220 5% 1/4W F
R532 1-247-897-11 CARBON 560K 5% 1/4W
R533 1-249-437-11 CARBON 47K 5% 1/4W
R541 1-249-441-11 CARBON 100K 5% 1/4W
R542 1-249-441-11 CARBON 100K 5% 1/4W
R551 1-249-417-11 CARBON 1K 5% 1/4W F
R552 1-249-438-11 CARBON 56K 5% 1/4W
R553 1-249-412-11 CARBON 390 5% 1/4W F
R554 1-249-438-11 CARBON 56K 5% 1/4W
R555 1-249-417-11 CARBON 1K 5% 1/4W F
R556 1-249-433-11 CARBON 22K 5% 1/4W
R557 1-249-441-11 CARBON 100K 5% 1/4W
0R558 1-208-603-11 METAL 0.1 20% 5W
R559 1-260-076-11 CARBON 10 5% 1/2W
0R560 1-208-603-11 METAL 0.1 20% 5W
0R561 1-212-881-11 FUSIBLE 100 5% 1/4W
R581 1-249-435-11 CARBON 33K 5% 1/4W
R582 1-249-435-11 CARBON 33K 5% 1/4W
R591 1-249-441-11 CARBON 100K 5% 1/4W
R592 1-249-441-11 CARBON 100K 5% 1/4W
R942 1-249-429-11 CARBON 10K 5% 1/4W
R943 1-249-417-11 CARBON 1K 5% 1/4W F
R974 1-249-429-11 CARBON 10K 5% 1/4W
R975 1-249-429-11 CARBON 10K 5% 1/4W
< THERMISTOR >
TH701 1-807-796-11 THERMISTOR
**************************************************************
1-681-143-11 SENSOR BOARD
***********
1-533-217- HOLDER, FUSE
**************************************************************
A-4475-786-A SUB TRANS BOARD, COMPLETE (E,EA,SP,IA)
*************************************
A-4476-633-A SUB TRANS BOARD, COMPLETE (TH)
*****************************
< CAPACITOR >
0C971 1-113-925-11 CERAMIC 0.01uF 20.00% 250V
(E,EA,SP,IA)
C973 1-126-933-11 ELECT 100uF 20.00% 16V
C975 1-126-768-11 ELECT 2200uF 20.00% 16V
C976 1-164-159-11 CERAMIC 0.1uF 50V
C977 1-164-159-11 CERAMIC 0.1uF 50V
C978 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN974 1-568-226-11 PIN, CONNECTOR 2P
